Grande
Trideck
Trideck
CHANGE MODEL
Select the second yacht
Add model
Main Technical Specifications
Length overall (incl. pulpit)
38,22 m (125’ 5’’)
Beam max
7,98 m (26’ 2’’)
Draft (incl. props at full load)
2,05 m (6' 9'')
Displacement (at full load)
190 t (418874 lb)
Length overall (incl. pulpit)
_
Beam max
_
Draft (incl. props at full load)
_
Displacement (at full load)
_
Project
Building material
GRP + Carbon Fibre
Exterior designer
Alberto Mancini
Interior designer
Achille Salvagni Architetti
Hull designer
P.L. AUSONIO Naval Architecture & Azimut Yachts R&D Dept.
Builder
Azimut Yachts
Keel
D2P Displacement to planing hull
Certifications
Rina Class Pleasure
Building material
_
Exterior designer
_
Interior designer
_
Hull designer
_
Builder
_
Keel
_
Certifications
_
Accommodations
Cabins
5/6 + 4 crew
Berths
10 + 6 crew
Head compartments
7 + 4 crew
Cabins
_
Berths
_
Head compartments
_
Performance
Engines
2 x 2400 hp MTU
2 x 2600 hp MTU
2 x 2600 hp MTU
Maximum speed (test load)
up to 23/25 kn
Cruising speed (performance test mass)
up to 19/20 kn
Engines
_
Maximum speed (test load)
_
Cruising speed (performance test mass)
_
Tank capacity
Fuel capacity
approx 22.500 l (5945 Gal)
Water capacity
approx 4000 l (1057 Gal)
Fuel capacity
_
Water capacity
_
